最大工作高度Max working height

2120mm

最大裝載高度Max pin height

1865 mm

最大卸載高度Max Dumping height

1405 mm

最大傾卸距離Max Dumping distance

505mm

最大卸載角度Max Dumping Angle

35°

總高度Total height

1350 mm

離地間隙Ground clearance

121 mm

軸距Wheel base

無鏟斗總長度Overall length without bucket

1495 mm

總寬度Total width

990 mm

鏟斗寬度Bucket width

1080mm

帶鏟斗總長度Total length with bucket

2245 mm

折疊踏班不帶鏟斗總長度overall length  without the bucket after  folding the pedal.

1990 mm

發動機Engine

潤通R420

百利通13.5HP

科普192（獨立油箱）

額定功率Rated Power (KW)

10.5Kw/3600rpm

10Kw/3600rpm

10Kw/3600rpm

轉速Rotating speed (rpm)

3600

3600

3000

噪聲Noise (Db)

≤95

≤95

≤95

液壓系統Hydraulic System

壓力Pressure (Mpa)

0-17

0-17

0-17

屬具流量Flow rate

0-18L

0-18L

0-15L

工作負載Operating Load

180 Kg(含屬具自重)

180 Kg(含屬具自重)

180 Kg(含屬具自重)

鏟斗容量Bucket Capacity

0.13m3

0.13m3

0.13m3

最大提升力Max Lifting Force

200 Kg

200 Kg

200 Kg

行駛速度Travel Speed

0-3Km/h

0-3Km/h

0-3Km/h

工作重量Operating Weight

630kg

630kg

630kg

油Oil

燃油箱Fuel tank

6.5L

6.5L

8.5L

發動機機油Engine oil

1.7L

1.7L

1.7L

液壓油箱
Hydraulic tank

30L

30L

30L
