ENGINE發動機

Emission Standard排放標準

EURO 5/ EPA

Make /Model 制造商/發動機型號

KUBOTA/V3800

Power /Rotation speed功率/轉速

93.4kw(127HP)@2200rpm

DRIVING SYSTEM行走系統

Maximum Travel speed最大行走速度

32km/h

Tire model/Number of tires 輪胎型號/數量

9.00-20/8

Driving type驅動形式

Hydraulic controlling 液壓控制

Steering type轉向形式

Steering wheel方向盤

TRANSMISSION 變速箱

Type 形式

Free shift(Stepless gear box)無級變速

BRAKE SYSTEM制動系統

Driving brake(Front axle)行車制動

Hydraulic brake(brake caliper)液壓制動

Parking brake駐車制動

Brake pedal lock腳踏板鎖止

Emergency brake緊急制動

Foot brake腳踏板制動

PERFORMANCE PARAMETER性能參數

Standard Bucket capacity挖斗容量

0.6m3

Swing speed回轉速度

12rpm

Maximum Grade ability最大爬坡度

25°

Maximum Bucket digging force挖斗最大挖掘力

91KN

Maximum Arm digging force斗桿最大挖掘力

55KN

Hydraulic system pressure液壓系統壓力

32Mpa

Machine weight整機重量

15300kg

Fuel tank燃油箱

252L

Hydraulic oil tank液壓油箱

160L

Engine oil capacity發動機油

11L

MACHINE SIZE尺寸

Overall dimension (L*W*H)整機尺寸

7677mm*2550mm*3377mm

Height of cabin駕駛室高度

3100mm

Wheel base/Tread 軸距/輪距

2600mm/1955mm

Minimum Ground clearance最小離地間隙

350mm

Swing radius at tail尾部回轉半徑

2365mm

Boom length動臂長度

4500mm

Arm length斗桿長度

2500mm

WORKING RANGE工作范圍

Maximum Digging height最大挖掘高度

8900mm

Maximum Dumping height最大卸載高度

6300mm

Maximum Digging depth最大挖掘深度

5180mm

Maximum Vertical digging depth最大垂直挖掘深度

4745mm

Maximum Digging radius最大挖掘半徑

8200mm

Minimum swing radius最小回轉半徑

2650mm

Maximum lifting height of dozer blade

推土鏟最大升起高度

368mm

Maximum cutting depth of dozer blade

推土鏟最大切割深度

100mm
